Important Elements

* 3 GE ports (1024 IP in maximum):

Bidirectional ports Data1 and Data2, maximum 512 IP in, maximum 32 IP out

Data port; maximum 128 IP in; front panel

* Maximum 840 Mbps per GE input

* Supports accurate PSI/SI editing, PID remapping, and PCR adjusting/CA filtering.

* 256 PIDS remapping per channel is supported.

* Support UDP/RTP/RTSP with 32 IP output via Data1 & Data2.

* 32 non-adjacent QAM carriers produced that complies with ITU-T J.83 A/B and DVB-C (EN 300 429)

* Adopts RS (204,188) encoding support

* Encourage network management via the web
